HP Measuring system 5300B and Battery pack 5310A Operating and service manual
5300B serial prefix 1704A
5310A serial prefix 1312A
Rev No.3, May 1977
Manual part no.: 05300-90035

English language, 94 pages

All pages 300dpi, grayscale (some colour) lossless LZW tiff scans, lossless ZIP PDF compression
Seamless scans, retouched and normalized, print ready. 142 MBytes.








TABLE OF CONTENTS:

GENERAL INFORMATION
1-1. Introduction
1-3. Description
1-5. Purpose and Use of Manual
1-8. Applications
1-10. Instrument Identification
1-14. Manual Changes and Options
1-16. Equipment Supplied and Accessories Available
1-18. Manual Microfiche
INSTALLATION
2-1. Introduction
2-3. Unpacking and Inspection
2-5. Storage and Shipment
2-8. Power Connection
2-13. Installation and Removal of Plug-On Modules
2-15. Portable Operation
2-18. Maintenance
2-20. Alternate Power Cables
OPERATION
3-1. Introduction
3-3. Accuracy
3-5. Front Panel
3-7. Rear Panel
3-10. 53008 Operating Procedures
3-12. 5310A Operating Procedures
THEORY OF OPERATION
4-1. Introduction
4-3. Overall Circuit Operation
4-10. Detailed Circuit Operation
4-12. Eight-Digit Display
4-18. Counter
4-23. Data Control ROM
4-27. Time Base
4-29. AIU9 Control
4-36. Time Base Reference Oscillator
4-38. Power Supply
4-50. AlJl Connector
4-52. 5310A Battery Pack
MAINTENANCE
5-1. Introduction
5-3. Recommended Test Equipment
5-5. Instrument Access
5-7. Periodic Maintenance
5-9. Maintenance and Repair
5-13. Instrument Troubleshooting
5-23. Diagnostic Test Card A
5-28. Diagnostic Test Card B
5-35. Diagnostic Test Card C
5-42. Diagnostic Test Card D
5-48. Alternate Method of Trouble Isolation
5-51. Oscillator Adjustment
5-53. Standard Oscillator Direct Count Measurement and Adjustment
5-56. Standby Oscillator Measured by Oscilloscope-Drift Method
5-58. Option 001 High Stability Time Base (TCXO) Measurementand Adjustment
5-60. HP 5310A Battery Pack
5-61. Battery Capacity Check
5-63. Replacing Internal Battery Supply
5-65. Removing A2 Power Supply Board
REPLACEABLE PARTS
6-1. Introduction
6-4. Ordering Information
MANUAL CHANGES AND OPTIONS
7-1. Introduction
7-3. 5300A Measuring System
7-5. Options
7-7. Field Installation of Option 001
7-9. Manual Changes
7-11. Newer Instruments
7-13. Older Instruments (5310A Battery Packs)
7-17. Older Instruments (5300B)
SCHEMATIC DIAGRAMS
8-1. Introduction
8-3. Schematic Diagram Notes, Assembly Numbers, andReference Designators
8-5. Reference Designations
8-7. Identification Markings on Printed-Circuit Boards

---
