59.00 EUR (63.70 USD)

SERVICEHANDBUCH (Service Manal) Book II
SCALAR NETWORK ANALYZER Type ZAS 393.0015.02
Edition 393.6788-2


-------------
This is Book II only! It covers geaneraly whole instrument and detailed information on Microprocesor, Graphic, Power and Video part of the instrument.
-------------
This book does not cover Operating of instrument (Book I)
This book DOES NOT cover detailed information on I/O board, Sequence controller, Analog unit, Keyboard unit, Z1 demodulator (Book III)

German and English language, 294 pages

Seamless scans
Text, images and schematics 300dpi, images/schematics grayscale, lossless PNG/ZIP PDF compression, 57 MBytes
Print ready: all pages double sided, with or without content.



TABLE OF CONTENTS
ENG
VOLUME II
4. Service manual for Complete Instrument
5. Service manual for Individual Modules
Microprocessor Module ....(393.1011.02)
Graphic Processor Module .(393.0615.02)
Power Unit ...............(393.5017.02)
Video-Control.............(375.5319.02)
Video Outpu-Stage.........(375.5219.02)

Function description, Testing, Adjustment, Troubleshooting, Mechanical, pats, SCH, PCB.


GER
Inhalt
BAND II
4. Serviceanleitung Gesamtgerat
5. Serviceanleitung fur die einzelnen Baugruppen
Mikroprozessor ....(393.1011.02)
Grafikprozessor ...(393.0615.02)
Netzteil ..........(393.5017.02)
Videoansteuerung ..(375.5319.02)
Videoendstufe .....(375.5219.02)

Funktionbeschreibung, Prufen und Abgleichen, Fehlersuche, Mechanischer, Stromlaufe, Schaltteillisten, Bestuckungsplane

---

Keywords: zas;network;scalar;rohde
File Size: 56.1 MBytes
